The coated α-Al2O3 separator has a much higher resistance to temperature effects than its polyolefin counterparts, retaining its dimensional integrity at temperatures as high as 200ºC. This eliminates the possibility of a short circuit during thermal runaway. Lithium ion batteries assembled as half-cells and full cells with coated α-Al2O3 separator exhibit electrochemical performance comparable with that of polyolefin separators at room temperature. However, the cells with coated alumina separator shows better cycling performance under extreme temperatures in the temperature range of -30°C to 60°C.
Lithium ion batteries with inorganic separators offer the advantage of safer operation.Unlike state-of-the-art polyolefin separators such as polypropylene (PP) which are selectively wettable with only certain electrolytes, the excellent electrolyte solvent wettability of α-Al2O3 allows the coated alumina separator to function with different electrolytes.
【Application】
It is mainly used for the coating material of positive and negative pole diaphragm of lithium battery, which is beneficial to the stability of the battery.
It is suitable for Lithium ion battery separator,and the battery can be used for electronic car, electronic intelligent products and energy storage products.
【Specification】
1. Chemical properties: Al2O3>99.9%
2. Color:white
3.PSD: D50=0.8-1.2um,D99<6um
ITEM | INDEX | ITEM | INDEX |
Al2O3% | 99.9 | D50 | 0.8-1.2um |
Ca% | <0.05 | D90 | <3um |
Fe% | <0.01 | D99 | <6um |
Na% | <0.4 | BET | 5-8m2/g |
【Product features】
The presence of the alumina can significantly improve the physical and chemical properties of battery separators. The alumina coating layer may reduce or prevent dendrite puncture, lithium plating and separator shrinkage during over-heating, hence significantly increasing safety performance for a lithium ion battery.
The alumina ceramic coating provides a skeleton for the flexible seperator, improves the wear resistance of the seperator, prevents lithium dendrite from piercing, reduces heat shrinkage, improves temperature resistance, and the pores are stable with temperature, which can effectively improve the safety performance of the battery.
1. Less magnetic foreign matters, stable electrical performance, low content of harmful ions;
2. High heat resistance, stable at high temperature;
3. The particle size distribution is very narrow, which can be coated with a very thin thermal insulation coating, with low thermal resistance; no small particles blocking Li + ion channel, no coarse particles scratching the film.
【Packing】 25kgs/poly-drum ,500kgs/pallet.
