Place of Origin:
China
Brand Name:
GONA
Certification:
ISO9001:2015
Contact Us
Beveled glass is widely used as a decorative glass feature in doors and windows. The main characteristic of beveled glass is that the edges are cut at an angle so as to give a different kind of look and finish to the glass. The edges act as a prism that tends to refract light and split it into the different colours of the rainbow .This gives depth and a third dimension to the glass. Beveled glass is usually ¼’’ thick but thicker tempered glass could also be used for beveling.
【Application】
It is suitable for optical spherical glass beveled & edge polished.
【Specification】
1. Chemical properties: TREO>94%, CeO2/TREO= 60-70%
2. Color: light yellow
3. PSD: D50=1.0-1.4um,D99<6um
ITEM | INDEX | ITEM | INDEX |
TREO% | 94 | D50 | 1.0-1.4um |
CeO2/ITREO% | 60-70% | D90 | <4um |
La2O3/TREO% | 20-30% | D99 | <6um |
【Product features】
(1) Strong versatility: the product has uniform particle distribution, can meet the requirements of smoothness and abrasion, and has a wide range of applications.
(2) No impurities: multiple screening procedures are adopted to remove impurities to ensure no scratches after use.
(3) Stable suspension: additives are added to keep the product in a good suspension state and easy to clean.
【Application methods】
Recommended specific gravity: 1.03-1.08, depending on the material and process parameters of the glass.
Applicable machine: flat polishing machine or spherical pendulum machine.
Suitable for workpiece: spherical lens with abrasion degree of 80-120, prism, motherboard substrate and other planar optical glass
【Packing】 25kgs/poly-drum ,500kgs/pallet;It can be according to customers requirements.
1 Q: How about the service ?
Answer:
1).24 hours for after-sale serive
2).more than 14 years experience in this kind machine field
3).fluent english ,communication barrier free. Point-to-point service help you solve the problems timely.
2 Q: What's your payment terms?
A:T/T AD
3 Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.
4 Q: What are your terms of payment?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shipment.
If you have other questions, please feel free to contact us.
Shanghai Gona Industrial Co.Ltd is founded in 2006, and located in Songjiang Industrial District, rounded by National Engineering research Center of Ultrafine Powder(NERCUP).Now we have three production bases and one R & D Center.One is located in Baotou city inner Mongolia which produces cerium oxide polishing powder;One is located in Zhejiang which produces alumina for Li+ battery separator.Another one and the R&D center are located in Shanghai.
