Chemical Stability Lithium Ion Car Battery Diaphragm Alumina Material


  Aluminum oxide has a wide range of applications in the field of batteries due to its high chemical stability, excellent insulation properties, and mechanical strength. It is mainly used for battery separator coating, solid electrolyte, electrode material modification, and battery shell protection, which can significantly improve the safety, cycle life, and energy density of batteries.

【Application】

It is mainly used for the coating material of positive and negative pole diaphragm of lithium battery, which is beneficial to the stability of the battery.
It is suitable for Lithium ion battery separator,and the battery can be used for electronic car, electronic intelligent products and energy storage products.


【Specification】

1. Chemical properties: Al₂O₃>99.9%
2. Color:white
3.PSD: D50=0.8-1.2um,D99<6um




【Product features】


Lithium ion batteries with alumina separator is fabricated for safety improvement. Alumina separator is coated on electrode by a scalable and cost-effective method.Lithium ion batteries with alumina separator perform better than conventional cells.

The presence of the alumina can significantly improve the physical and chemical properties of battery separators. The alumina coating layer may reduce or prevent dendrite puncture, lithium plating and separator shrinkage during over-heating, hence significantly increasing safety performance for a lithium ion battery

1. Less magnetic foreign matters, stable electrical performance, low content of harmful ions;
2. High heat resistance, stable at high temperature;
3. The particle size distribution is very narrow, which can be coated with a very thin thermal insulation coating, with low thermal resistance; no small particles blocking Li + ion channel, no coarse particles scratching the film.




【Packing】 25kgs/poly-drum ,500kgs/pallet.



1.Q:Why is aluminum oxide coating applied to battery separators?

A:The core purpose is to enhance the thermal stability and safety of the separators.

2. Q:How to choose the particle size and morphology of alumina?

A:Alpha type, with a median particle size (D50) typically ranging from 0.5 μm to 1.0 μ m

3 Q: Is it better to have a thicker ceramic coating?

A:Further improve mechanical and thermal stability, but this will result in a loss of energy density

4 Q: What is the minimum order quantity?.

A:The sample weighs 2kg and is provided for free, but the shipping fee needs to be paid by the buyer
