Place of Origin:
China
Brand Name:
GONA
Certification:
ISO9001：2015
Model Number:
PL
Contact Us
Sapphire will be used as the substrate/substrate in many material production, including semiconductor. The main raw material consumed in the production of sapphire crystal is high-purity aluminum oxide. high-purity aluminum oxide powder can improve the purity and transparency of sapphire crystal, thereby improving the performance of sapphire materials.
【Application】
The substrate itself may have some special functions and uses, or it may only be used as a substrate for new materials, and it has no other special uses. In the past, the materials used as film substrates were glass, ceramics and metal plates, but now the mainstream are sapphire, Si and SiC
【Specification】
1. Chemical properties: Al2O3>99.9%
2. Color:white
3.PSD: D50=0.5-0.8um,D99<4um
| ITEM | INDEX | ITEM | INDEX |
| Al2O3% | 99.9 | D50 | 0.5-0.8um |
| Ca% | <0.05 | D90 | <2um |
| Fe% | <0.01 | D99 | <4um |
| Na% | <0.4 | BET | 5-8m2/g |
【Product features】
The presence of the alumina can significantly improve the physical and chemical properties of battery separators. The alumina coating layer may reduce or prevent dendrite puncture, lithium plating and separator shrinkage during over-heating, hence significantly increasing safety performance for a lithium ion battery
The alumina ceramic coating provides a skeleton for the flexible seperator, improves the wear resistance of the seperator, prevents lithium dendrite from piercing, reduces heat shrinkage, improves temperature resistance, and the pores are stable with temperature, which can effectively improve the safety performance of the battery.
1. Less magnetic foreign matters, stable electrical performance, low content of harmful ions;
2. High heat resistance, stable at high temperature;
3. The particle size distribution is very narrow, which can be coated with a very thin thermal insulation coating, with low thermal resistance; no small particles blocking Li + ion channel, no coarse particles scratching the film.
【Packing】 25kgs/poly-drum ,500kgs/pallet.
1 Q: How about the packing?
A:Usually we provide the packing as 50 kg Iron Drum or 25 plastic Drum ,if you have special requirements on them, we will according to you.
2. Q:What's the guarantee ?
Answer:
1). Our guarantee for 12 months.
2). 18 hours' technical support by email, video or calling
3). English manual and video tutorial
4). 24 hours on line service each day, free professional technical support.
3 Q: What are your terms of payment?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shipment.
If you have other questions, please feel free to contact us.
4.Q:Why your price isn't the lowest price compared with others company or factories ?
A:1) We are a innovative enterprises, not only a produce factory. We have a a professional and experienced technical elite team.
2)Compared with the same level brand, we have the same functions and components, but our price is the most competitive. At the same time, our after sales service is satisfactory. We have a good reputation in our customers.
Shanghai Gona Industrial Co.Ltd is founded in 2006, and located in Songjiang Industrial District.Now we have three production bases and one R & D Center.One is located in Baotou city inner Mongolia which produces cerium oxide polishing powder;One is located in Zhejiang which produces alumina for Li+ battery separator.Another one and the R&D center are located in Shanghai.
